µ¿ÀÛ ¿ø¸® |
Ultrasonic, Pulse Echo Measurement Method |
ÃøÁ¤ ¹üÀ§ |
0.60 mm to 508 mm |
2.00 mm to 127.0 mm(Dual-Multi Measurement Mode-only DM5E, DM5E DL) |
ÃøÁ¤ ºÐÇØ´É |
0.01, 0.1 mm (µÑÁß ¼±Åð¡´É) |
¹°¸®Àû ¼Óµµ ¹üÀ§ |
0.508 to 18699 m/sec |
¹°¸®Àû ¼Óµµ ºÐÇØ´É |
1 m/s |
´ÜÀ§ |
Inch or Millimeter |
±³Á¤ |
One-Point Cal, On-Block and Off-Block, Two-Point Cal |
Pulser |
Excitation Pulse,Spike Pulser |
Àü¾Ð |
120 V into 50 ohm Load |
Reciver |
500KHz to 12 MHz @ -3 dB |
Gain |
Automatic Gain Control |
ȸé ŸÀÔ°ú ÇØ»óµµ |
LCD, 64 x 128 Pixels |
ȸé Å©±â |
53.0 mm x 27.0 mm with Backlight and Adjustable Contrast |
Update rate |
4Hz or 8Hz, User Selectable, 24Hz Scan Mode Capture Rate |
µÎ²² °ª Ç¥½Ã |
NORMAL View Mode : 5 Digit, 10.6 mm (0.4¡±) High |
B-SCAN View Mode : 5 Digit, 2.55 mm (0.1¡±) High |
Display of Last Reading |
Solid Filled or Hollow Digits Indicate Coupled or Uncoupled Condition |
Setups |
9 Standard Setups for Probes |
¾Ë¶÷ ¼³Á¤ |
Range of 0.25 mm to 508 mm |
º£Å͸® |
2¡°AA¡±Size Batteries |
»ç¿ë ½Ã°£/¹èÅ͸® ¼ö¸í |
Approximately 60 Hours |
Àåºñ on/off |
Selectable ALWAYS ON or AUTO OFF |
¾ð¾î |
English, German, French, Spanish, Italian, Russian, Japanese and Chinese |
I/O Ä¿³ØÅÍ |
Transducer Dual Lemo 00 (coax) |
Mini-USB Mini-USB to PC |
»ç¿ë ¿Âµµ |
Operating -10¡ÆC to +50¡ÆC (+10¡ÆF to +120¡ÆF) |
Storage -20¡ÆC to +60¡ÆC (-10¡ÆF to +140¡ÆF) |
¹«°Ô |
223g |
Å©±â |
138 mm x 32 mm x 75 mm |
Shock |
IEC 68-2-27 Ea, as per Mil Std 810C Method 516.2 Procedure I with a |
15g 11ms Impulse Half Sinusoidal Wave Applied 6 Times per Axis |
Sealing |
Sealing IEC529 / IP54, Dust Proof/Dripping Water Proof as per |
IEC 529 Specifications for IP54 Classification |
